T Profile DATA SHEET

For hidden aluminium connections

Eurotec’s T-profile is a hidden aluminium wood connector for use both indoors and outdoors. Suitable in terms of geometry for right-angled and inclined connections of individual beams in wood / wood and wood / concrete applications. Can be combined with our rod dowel, which is screwed in through the T-profile as part of a selfdrilling process.

Material: High-quality aluminium

• Suitable for service classes 1 and 2 according to DIN EN 1995 – Eurocode 5
• Available in a length of 2.00 m
• Measurement scale for individual profile cutting on the construction site

Instructions for use

1. No need for pre-drilling with the self-drilling EST rod dowel (Ø 7.5)
2. Hole pattern for the 5.0 x 50 mm angle-bracket screw
3. Rock concrete screw (Ø 7.5) for the wood / concrete joint
