We stock a large range of high quality construction & marine fixings. As well as the standard range we specialise in larger sizes, longer lengths and larger diameters of screws and fasteners.
Diameter (d) | 7,5 mm |
Total length (l) | 212 mm |
Head shape | Countersunk head |
Diameter of head (dk) | 11 mm |
Drive size | TX30 |
Drive shape | Inner multi-tooth |
Thread length (b) | 137 mm |
Height of head (k) | 2,6 mm |
Measurement b1 (b1) | 40 mm |
- No pulling force between cover frame and masonry
- Can be used without dowels in the masonry
- optimal torque transmission, no "come-out" effect of the bit
drilling diameter:
over frame: 6,5 mm
concrete: 6,5 mm
other masonry: 6,0 mm
cellular concrete: no pre-drilling necessary
drilling dephts:
Mind. 30 mm = concrete
Mind. 40 mm = lime stone
Mind. 50 mm = pumice stone
Mind. 60 mm = lightweight concrete, vertical corning brick
- head diameter 11 mm
- TX drive
- small countersunk head
