We stock a large range of high quality construction & marine fixings. As well as the standard range we specialise in larger sizes, longer lengths and larger diameters of screws and fasteners.
Quality TCT blades featuring a Triple Chip Ground (TCG) tooth configuration for fast and clean cuts in various metal sections
TOOTH TYPE KEY:
ATB Tooth: Suitable for most applications including rip saws and table saws.
ATB Neg Tooth: Suitable for use on mitre saws and chop saws. Minimises snatching and pick up of material.
ATB 30 Degree Tooth: Suitable for laminate material to reduce damage to the surface. Fast cut.
TCG Tooth: Suitable for materials such as aluminium, plastic, wood laminates and other manmade materials. Leaves a chip-free finish due to its bevelled corner tooth which cuts first followed by a flat top tooth.
CIRCULAR SAW BLADE CUT TYPE:
WOOD - COARSE FINISH
These blades have between 16 and 20 teeth for smaller lades and 28 teeth for blades with a diameter greater than 190mm. Suitable for ripping through woods such as softwood, hardwood and plywood.
WOOD - MEDIUM FINISH
These blades have between 20 and 28 teeth for smaller blades and 40 teeth for blades with a diameter greater than 190mm. Suitable for cutting through woods such as softwood, hardwood and plywood.
WOOD - FINE FINISH
These blades have between 40 and 80 teeth; 40 teeth for blades with a diameter of up to 190mm, 60 teeth for 210-260mm diameter and 80 teeth for blades with a larger diameter. Suitable for cutting through woods such as softwood, hardwood, particle board, MDF, single-sided wood laminates, hardboard and plywood.
WOOD - EXTRA FINE FINISH
Theses blades have between 60 and 100 teeth; 60 teeth for blades with a diameter of up to 190mm, 80 teeth for 210-260mm diameter and 100 teeth for blades with a larger diameter. Use for an extra fine finish cut through woods such as softwood, hardwood, particle wood, MDF, wood laminates, hardboard and plywood.
ALU/PLASTIC/LAMINATES - FINE FINISH
These blades have Triple Chip Tooth configurations and have between 40 and 100 teeth. Suitable for cutting non-ferrous metals including aluminium, plastic and wood laminates.
BLADE CUTTING SPEED
BLADE | FASTER | - | SLOWER |
Diameter |
Thin Sections Up to
1.6mm (20-45m/sec) |
Medium Sections
2-4mm (20-25 m/sec) |
Thick Sections
5-12mm (20-30 m/sec) |
136mm | 2800-6300 rpm | 2800-4900 rpm | 2800-4200 rpm |
165mm | 2400-5300 rpm | 2400-4200 rpm | 2400-3600 rpm |
180mm | 2100-4800 rpm | 2100-3700 rpm | 2100-3200 rpm |
185mm | 2100-4800 rpm | 2100-3700 rpm | 2100-3200 rpm |
230mm | 1800-4100 rpm | 1800-3200 rpm | 1800-2700 rpm |
255mm | 1500-3600 rpm | 1500-3100 rpm | 1500-2100 rpm |
305mm | 1250-2800 rpm | 1250-2200 rpm | 1250-1900 rpm |
355mm | 1100-2400 rpm | 1100-1900 rpm | 1100-1600 rpm |
